- 3-step multipower and dual CCT 3000/4000K
- Homogenous light output
- Long lifetime of 50.000h L80B10 at Ta 25°C
- Microwave motion sensor kit available with master-slave function of maximum 250W
- Emergency kit available with 300lm output energy backup lasting for 3 hours
| General | |
|---|---|
| Rated power | 14/20/30W |
| CCT | 3000K 4000K |
| Useful lumen | 1330/1900/2850lm 1400/2000/3000lm |
| Light efficacy | 95/95/95lm/W 100/100/100lm/W |
| Beam angle | 120° |
| Electrical data | |
|---|---|
| Nominal voltage | 220-240V |
| Frequency | 50/60Hz |
| Rated input current | 80/115/170mA |
| Power Factor | >0.9 |
| THD | <20% |
| Inrush current ipeak | 14.0A |
| Inrush current time | 600µs |
| Max. number of luminaires per miniature circuit breaker B10 | 8 |
| Max. number of luminaires per miniature circuit breaker B16 | 12 |
| Max. number of luminaires per miniature circuit breaker C10 | 13 |
| Max. number of luminaires per miniature circuit breaker C16 | 21 |
| Surge protection | 1000V |
| Protection class | Class I |
| Functions | |
|---|---|
| Dimmability | No |
| Sensor | No |
| Emergency | No |
| Photometric data | |
|---|---|
| CRI | RA80 |
| UGR | N/A |
| SDCM | 6 |
| Flicker percentage | ≤3% @100Hz |
| Photobiological safety group | RG0 |
| Mounting & Application | |
|---|---|
| Mounting method | Surface mounted |
| Loop-through | Yes |
| IP rating | IP44 |
| IK rating | IK03 |
| Glow wire test | 650°C |
| Lifetime L70/B50 | 70000h |
| Lifetime L80/B10 | 50000h |
| Switching cycles | 100000 |
| Operating temperature | -30 - 40°C |
| Application temperature | 25°C |
| Warranty | 5 years |
| Materials & Colour | |
|---|---|
| Housing material | Steel |
| Cover material | PMMA |
| Finishing colour | White |
| Logistical data | |
|---|---|
| EAN | 4892657121933 |
| Product height | 130mm |
| Product diameter | 500mm |
| Product net weight | 1.230kg |
