- Easy installation and toolless wiring
- Fixing bracket adjustable up to 355°
- Special design of mounting bracket allows more spacious for power drill
- Stainless 304 screws equipped
- DC input compatible (DC180-260V)
- Attachable PIR module available
| General | |
|---|---|
| Rated power | 45.0W |
| CCT | 3000K |
| Useful lumen | 4650lm |
| Light efficacy | 103lm/W |
| Beam angle | 110° |
| Electrical data | |
|---|---|
| Nominal voltage | 220-240V |
| Frequency | 50/60Hz |
| Power Factor | >0.9 |
| THD | 0.2 |
| Inrush current ipeak | 35.6A |
| Inrush current time | 150µs |
| Max. number of luminaires per miniature circuit breaker B10 | 6 |
| Max. number of luminaires per miniature circuit breaker B16 | 9 |
| Max. number of luminaires per miniature circuit breaker C10 | 10 |
| Max. number of luminaires per miniature circuit breaker C16 | 16 |
| Surge protection | 2000V |
| Protection class | Class II |
| Functions | |
|---|---|
| Dimmability | No |
| Sensor | No |
| Emergency | No |
| Photometric data | |
|---|---|
| CRI | RA80 |
| UGR | N/A |
| SDCM | 6 |
| Flicker percentage | ≤30% @100Hz |
| Photobiological safety group | RG1 |
| Mounting & Application | |
|---|---|
| Mounting method | Surface mounted |
| Loop-through | No |
| IP rating | IP65 |
| IK rating | IK08 |
| Glow wire test | 650°C |
| Lifetime L70/B50 | 50000h |
| Lifetime L80/B10 | 30000h |
| Switching cycles | 100000 |
| Operating temperature | -30 - 50°C |
| Application temperature | 25°C |
| Warranty | 5 years |
| Materials & Colour | |
|---|---|
| Housing material | PC |
| Cover material | PC |
| Finishing colour | Black |
| Logistical data | |
|---|---|
| Product length | 197mm |
| Product width | 260mm |
| Product height | 84mm |
| Product net weight | 0.550kg |
