- Non-maintained operation mode
- Super slim design
- Overcharge and over-discharge protection, over-temperature protection, short circuit protection
- Status indicator
- IP54 protection
- Corridor optics
| General | |
|---|---|
| Rated power | 3.1W |
| CCT | 6000K |
| Useful lumen | 135lm |
| Light efficacy | 44lm/W |
| Beam angle | 150° |
| Electrical data | |
|---|---|
| Nominal voltage | 220-240V |
| DC input voltage | 3.2V |
| Frequency | 50/60Hz |
| Rated input current | 0mA |
| Power Factor | 0.5 |
| Inrush current ipeak | 10.6A |
| Inrush current time | 200µs |
| Max. number of luminaires per miniature circuit breaker B10 | 20 |
| Max. number of luminaires per miniature circuit breaker B16 | 31 |
| Max. number of luminaires per miniature circuit breaker C10 | 32 |
| Max. number of luminaires per miniature circuit breaker C16 | 53 |
| Surge protection | 500V |
| Protection class | Class II |
| Functions | |
|---|---|
| Dimmability | No |
| Sensor | No |
| Emergency | Yes |
| Power in emergency mode | 1.0W |
| Lumen output in emergency mode | 135lm |
| CCT in emergency mode | 6000K |
| Emergency battery duration | 3h |
| Type of emergency operation test | Non-maintained |
| Photometric data | |
|---|---|
| CRI | RA80 |
| UGR | N/A |
| SDCM | 6 |
| Photobiological safety group | RG0 |
| Mounting & Application | |
|---|---|
| Mounting method | Surface mounted |
| Loop-through | No |
| IP rating | IP54 |
| IK rating | IK02 |
| Glow wire test | 850°C |
| Lifetime L70/B50 | 50000h |
| Switching cycles | 100000 |
| Operating temperature | 0 - 45°C |
| Application temperature | 25°C |
| Warranty | 3 years |
| Materials & Colour | |
|---|---|
| Housing material | PC |
| Finishing colour | White |
| Logistical data | |
|---|---|
| Product length | 130mm |
| Product width | 130mm |
| Product height | 35mm |
| Product net weight | 0.243kg |
